| Input Impedance |
: |
4 ohm (Nominal) |
|
| Anechoic Sensitivity |
: |
93 dB/2.83 V/1 m
(90 dB/ 1 W/ 1 m) |
|
| Frequency Response |
: |
+1. -1.5 dB
(60 Hz – 22 kHz) |
|
| Low Frequency Extension |
: |
-3 dB: 54 Hz
-10 dB: 35 Hz |
|
| Enclosure Resonance Frequency |
: |
33 Hz |
|
| Long Term Maximum Power (IEC265-5) |
: |
200 W continuous average; 800 W peak |
|
| Recommended Amplifier Power |
: |
150 W - 1000 W (rating into 4-ohm load) |
|
| High Frequency Control |
: |
0 dB, -1 dB (2.5 to 20 kHz) |
|
| Distortion, 96 dB SPL, 1 m |
: |
2nd Harmonic (below 120 Hz): <1.5%
3rd Harmonic (below 120 Hz): <1%
2nd Harmonic (120 Hz to 20 kHz): <0.5%
3rd Harmonic (120 Hz to 20 kHz): <0.4% |
|
| Distortion, 102 dB SPL, 1 m |
: |
2nd Harmonic (below 120 Hz): <1.5%
3rd Harmonic (below 120 Hz): <1%
2nd Harmonic (80 Hz to 20kHz): <1%
3rd Harmonic (80 Hz to 20kHz): <1%
(<0.4%, 250 Hz - 20 kHz) |
|
| Power Nonlinearity |
: |
30 W (20 Hz to 20 kHz): <0.4 dB
100 W (20 Hz to 20 kHz): <1.0 dB |
|
| Low-Mid Frequency Crossover |
: |
4th Order Acoustic Linkwitz-Riley: 250 Hz |
|
| Mid-High Frequency Crossover |
: |
4th Order Acoustic Linkwitz-Riley: 2.2 kHz |
|
