| Frequency Response |
: |
(-6 dB) 28 Hz - 80 Hz |
|
|
|
| Enclosure Resonance Frequency |
: |
28 Hz |
|
| Low-To-High Crossover Frequency |
: |
80 Hz (4th order electroacoustic Linkwitz-Riley) |
|
| Distortion, 96 dB SPL/ 1 m |
: |
N/A |
|
| Low Frequency (<80 Hz) |
: |
N/A |
|
|
|
|
|
| Maximum Continuous SPL |
: |
>112 dB SPL / 1 m (35 Hz - 80 Hz) |
|
| Maximum Peak SPL |
: |
>115 dB SPL / 1 m (35 Hz - 80 Hz) |
|
| Calibrated Input Sensitivity |
: |
XLR or 1/4" |
|
| Selectable -10 dBV +4 dBu, +8 dBu |
: |
96 dB / 1 m |
|
| Power Nonlinearity (20 Hz - 200 Hz): |
: |
N/A |
|
|
|
|
|
| Power / Clip / Bypass Indicators |
: |
Green LED - normal operation
Amber LED - bypass mode
Red LED - Limiter activated |
|
| Low Frequency Topology |
: |
Class A-B, all discrete |
|
| Sine Wave Power Rating |
: |
260 W (<0.5% THD into rated impedance) |
|
| THD + N, 1⁄2Power |
: |
<0.05% |
|
| AC Input Voltage |
: |
115 VAC, 60 Hz (230VAC, 50 Hz – model LSR6312SP/230) |
|
| AC Input Voltage Operating Range |
: |
±15%
|
|
